SPECS Specifications subject to change without notice.
FRAME FACT 11m carbon chassis and rear-end, asymmetrical design, 29 Trail
Geometry, SWATTM Door integration, flip chip Head Tube/Bottom
Bracket adjustment, threaded BB, fully enclosed internal cable
routing, 12x148mm UDH compatible rear spacing, sealed cartridge
bearing pivots, 130mm of travel
REAR SHOCK FOX FLOAT DPS Factory, Rx Trail Tune, EVOL Air sleeve, Kashima
Coat, 3-position adjustment w/ Open Mode Adjustment, 190x45mm
FORK FOX FLOAT 34 Factory, GRIP2 damper, Kashima Coating,
15x110mm, 44mm offset, 140mm of travel
STEM Deity, 35.0mm
HANDLEBARS Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree
backsweep, 30mm rise, 780mm, 35.0mm
GRIPS Deity Grips
FRONT BRAKE SRAM Code Ultimate Stealth, 4-piston caliper, hydraulic disc,
200mm HS2 Rotor
REAR BRAKE SRAM Code Ultimate Stealth, 4-piston caliper, hydraulic disc,
180mm HS2 Rotor
SHIFT LEVERS SRAM AXS POD Ultimate Controller
REAR DERAILLEUR SRAM XX Eagle Transmission Derailleur
CASSETTE SRAM XX SL Eagle Transmission Cassette, 12spd, 10-52t
CHAIN SRAM XX Eagle
CHAIN SRAM XX SL Eagle Transmission Flattop Chain
CRANKSET SRAM XX Eagle Crankset, Carbon, Integrated Guard, 55mm
Chainline, S1:165mm, S2-S5: 170mm, S6: 175mm
CHAINRINGS 32T
BOTTOM BRACKET SRAM DUB, BSA 73mm Wide, Threaded
RIMS Roval Control 240, hookless carbon, 29mm inner width, hand-built,
2Bliss Ready
FRONT HUB DT Swiss 240, sealed cartridge bearings, 15x110mm spacing, 28h
REAR HUB DT Swiss 240, Ratchet EXP, 36t engagement, SRAM XD driver
body, 12mm thru-axle, 148mm spacing, 28h
SPOKES DT Swiss Competition Race
FRONT TIRE Butcher, GRID casing, GRIPTON® T9 compound, 29x2.3"
REAR TIRE Purgatory, GRID casing, GRIPTON® T7 compound, 29x2.3"
INNER TUBES Standard, Presta valve
SADDLE Bridge, 155/143mm, Hollow Ti-rails
SEATPOST RockShox Reverb AXS, 30.9, 1X remote, (S1:100mm, S2: 125mm,
S3: 150mm, S4-S6: 170mm)
SEAT BINDER Alloy, 38.6mm
Weight 12.75kg (28 lb, 1.7 oz)
Weight Size S4
