Alloy Frame & LinkVirtual 4 link kinematic VLK29x2.6 / Boost 148x12mm UDH160mm travel / Bosch SmartSystem / Integr. removable Battery1.8" HeadtubeCentral Kickstand MountIntegr. Cable
TravelFront: 160mm / Rear: 160mm
ForkRockShox Domain Air15x110mm QR axle / 1.8" Tapered SteererReb. Adj. / 2 Modes / Lockout / 160mm travel / E-Bike
Rear ShockFOX Float EVOL eRIDE Trunnion3 modes / Lockout-Trail-DescendDPS / Reb. Adj.Travel 160mm / 205x60mm
Remote SystemSCOTT TwinLoc 2 TechnologySuspension & Dropper Remote3 modes
Drive UnitBosch Performance CXEU: 25kmh / INT: 20mph
BatteryPowerTube 750Wh
DisplayBosch LED Remote & Kiox 300
Charger4A Charger
Rear DerailleurShimano XT / 12 Speed
ShiftersShimano SL-M6100
CranksetFSA CK-745 165mm / 34T
Chainguidee*thirteen / e*spec Slider
ChainringFSA W0138+WB499 / 34T / Steel
ChainShimano CN-M6100
CassetteShimano CS-M6100 / 10-51T
BrakesSRAM DB8 4 Piston Disc
RotorSRAM Centerline CL Rotors 200mm F&R
HandlebarSyncros Hixon 2.0 / Alloy 6061D.B.12mm rise / 9° / 780mmSyncros Endurance lock-on grips
H'stemSyncros AM2.0 / 6061 Alloy31.8mm / 4° / 1 1/8"
SeatpostSyncros Duncan Dropper Post 2.5Size S 125mm / Size M 150mm / Size L 170mm Size XL 200mm
SeatSyncros Tofino 2.5 Regular
HeadsetAcros / 1.8"ZS66 OD74 / integr. Cable
Hub (Front)Shimano HB-MT410-B CL / 15x110mm
Hub (Rear)Shimano FH-MT410-B CL / Boost 12x148mm
SpokesStainless Black
RimsSyncros MD30 / 32H / 30mm / Pin JointTubeless ready
Front TireMaxxis Dissector 29x2.6"120TPI Foldable BeadEXO+ / TR Tubeless ready3C Maxx Terra
Rear TireMaxxis Dissector 29x2.6"120TPI Foldable BeadEXO+ / TR Tubeless ready3C Maxx Terra
LightsSyncros integrated rear fender lightFront Light Cable pre-installed
Approx weights in KG26.5 (with tubes)
Approx weights in LBS58.42 (with tubes)
Max. System Weight128kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
